All Expedition Series drawer systems ship assembled and bedlined

GX460 Expedition Series Drawer System


Estimated Production Lead Time: 12-14 Weeks





A CNC cut Drawer System designed to perfectly fit the Lexus GX 460. All pieces are cut from high grade plywood and come with a Polyurea Beliner Coating. Outfitted with heavy duty locking drawer slides, internal dividers, and removable wings, the SHW Off-Road drawer system will keep you organized and will outlive your GX. You can even choose what side the fridge slide is on!

All SHW drawer systems are made in Winchester, KY and include freight to the nearest Tforce freight terminal.

*Third row seats must be removed

*Hidden Drawer is only available with the small refrigerator tray

*Internal Dividers on drawer opposite of fridge slide only


  • Fits 2010-2022 Lexus GX460

  • Two drawers

  • Tilting fridge slide (optional) available in three different sizes

  • Wings included

  • Polyurea (bed liner) coating

  • Sleeping platform optional add on

  • Table top optional add on

  • Weighs approximately 140bs

Internal Drawer Dimensions

  • Medium Fridge
    • Fridge Side Drawer: 32.3"L X 20.9"W X 5.6"H
    • Opposite Side Drawer: 32.3"L X 12.7"W X 9.4"H
  • Large Fridge
    • Fridge Side Drawer: 32.3"L X 24.9"W X 5.6"H
    • Opposite Side Drawer: 32.3"L X 8.8"W X 9.4"H

External Drawer System Dimensions: 38"L X 42"W X 12.6"H

Installation Instructions
